BLS CAPTCHA Bildreihenfolge und Handhabung der Rasterantwort

BLS CAPTCHAs zeigen Bildraster an, in denen Benutzer Bilder auswählen oder neu anordnen müssen. In diesem Leitfaden werden Rasterlayouts, Antwortformate und die korrekte Übermittlung von Lösungen behandelt.

BLS-Grid-Challenge-Typen

Bildbestellung

Der Benutzer muss Bilder in einer bestimmten Reihenfolge anordnen (z. B. aufsteigende Zahlen, alphabetische Reihenfolge).

Bildauswahl

Der Benutzer muss auf bestimmte Bilder klicken, die einer Beschreibung entsprechen (z. B. „Alle Bilder mit Text auswählen“).

Musterübereinstimmung

Der Benutzer muss identifizieren, welche Bilder mit einem präsentierten Muster oder Muster übereinstimmen.

Rasterlayout-Zuordnung

# grid_mapping.py

# BLS grids typically use 3x3 or 4x4 layouts
# Each cell maps to an index:

# 3x3 grid:
# [0] [1] [2]
# [3] [4] [5]
# [6] [7] [8]

# 4x4 grid:
#  [0]  [1]  [2]  [3]
#  [4]  [5]  [6]  [7]
#  [8]  [9] [10] [11]
# [12] [13] [14] [15]

def grid_position(index, cols=3):
    """Convert flat index to row, column."""
    return index // cols, index % cols


def index_from_position(row, col, cols=3):
    """Convert row, column to flat index."""
    return row * cols + col


# Example: For a 3x3 grid, position (1, 2) = index 5
print(grid_position(5, cols=3))   # (1, 2)
print(index_from_position(1, 2))  # 5

Lösen von BLS Grid CAPTCHAs

# solve_bls_grid.py
import requests
import time
import os
import json


def solve_bls_grid(sitekey, pageurl, instructions=None):
    """Solve a BLS grid CAPTCHA and get response indices."""
    api_key = os.environ["CAPTCHAAI_API_KEY"]

    payload = {
        "key": api_key,
        "method": "bls",
        "sitekey": sitekey,
        "pageurl": pageurl,
        "json": 1,
    }
    if instructions:
        payload["instructions"] = instructions

    resp = requests.post(
        "https://ocr.captchaai.com/in.php",
        data=payload,
        timeout=30,
    )
    result = resp.json()
    if result.get("status") != 1:
        raise RuntimeError(f"Submit failed: {result.get('request')}")

    task_id = result["request"]

    time.sleep(10)
    for _ in range(30):
        resp = requests.get("https://ocr.captchaai.com/res.php", params={
            "key": api_key,
            "action": "get",
            "id": task_id,
            "json": 1,
        }, timeout=15)
        data = resp.json()
        if data.get("status") == 1:
            return data["request"]
        if data["request"] != "CAPCHA_NOT_READY":
            raise RuntimeError(data["request"])
        time.sleep(5)

    raise TimeoutError("BLS grid solve timeout")

Grid-Antworten analysieren

# parse_response.py
import json


def parse_grid_response(solution):
    """Parse CaptchaAI BLS response into actionable grid data."""
    # Solution may be JSON or comma-separated indices
    if isinstance(solution, str):
        try:
            parsed = json.loads(solution)
            return parsed
        except json.JSONDecodeError:
            pass

        # Try comma-separated indices
        if "," in solution:
            return [int(x.strip()) for x in solution.split(",")]

        # Single value
        return [solution]

    return solution


def format_for_submission(indices, grid_size=9):
    """Format indices for form submission."""
    # Some sites expect a bitmask
    bitmask = ["0"] * grid_size
    for idx in indices:
        if isinstance(idx, int) and 0 <= idx < grid_size:
            bitmask[idx] = "1"

    return {
        "indices": indices,
        "bitmask": "".join(bitmask),
        "count": len(indices),
    }

Injizieren von Grid-Lösungen mit Selenium

# inject_grid.py
from selenium.webdriver.common.by import By
from selenium.webdriver.support.ui import WebDriverWait
from selenium.webdriver.support import expected_conditions as EC
import time


def click_grid_cells(driver, indices):
    """Click specific grid cells based on solution indices."""
    wait = WebDriverWait(driver, 10)

    # Find all grid cells
    cells = wait.until(
        EC.presence_of_all_elements_located(
            (By.CSS_SELECTOR, ".captcha-grid .cell, .bls-grid img, .grid-item")
        )
    )

    for idx in indices:
        if isinstance(idx, int) and idx < len(cells):
            cells[idx].click()
            time.sleep(0.3)  # Brief delay between clicks


def set_order_sequence(driver, ordered_indices):
    """Click grid cells in the correct order for ordering challenges."""
    wait = WebDriverWait(driver, 10)

    cells = wait.until(
        EC.presence_of_all_elements_located(
            (By.CSS_SELECTOR, ".captcha-grid .cell, .bls-grid img")
        )
    )

    for idx in ordered_indices:
        if isinstance(idx, int) and idx < len(cells):
            cells[idx].click()
            time.sleep(0.5)  # Ordering needs pauses between clicks


def inject_hidden_response(driver, solution_value):
    """Set the solution in a hidden input field."""
    driver.execute_script("""
        var inputs = document.querySelectorAll(
            'input[name*="captcha"], input[name*="response"], #captcha-answer'
        );
        for (var i = 0; i < inputs.length; i++) {
            inputs[i].value = arguments[0];
        }
    """, str(solution_value))

Kompletter BLS-Grid-Flow

# full_flow.py
from selenium import webdriver
from selenium.webdriver.common.by import By
from selenium.webdriver.support.ui import WebDriverWait
from selenium.webdriver.support import expected_conditions as EC


def handle_bls_grid(driver, pageurl):
    """Complete BLS grid CAPTCHA handling."""

    wait = WebDriverWait(driver, 15)

    # Wait for CAPTCHA to load
    captcha = wait.until(
        EC.presence_of_element_located(
            (By.CSS_SELECTOR, "[data-sitekey], .bls-captcha")
        )
    )
    sitekey = captcha.get_attribute("data-sitekey")

    # Get instructions
    instructions = None
    try:
        inst = driver.find_element(By.CSS_SELECTOR, ".captcha-instructions")
        instructions = inst.text.strip()
    except Exception:
        pass

    # Solve via CaptchaAI
    solution = solve_bls_grid(sitekey, pageurl, instructions)
    parsed = parse_grid_response(solution)

    # Determine response method
    grid_cells = driver.find_elements(
        By.CSS_SELECTOR, ".captcha-grid .cell, .bls-grid img"
    )

    if grid_cells:
        # Click-based response
        if isinstance(parsed, list) and all(isinstance(x, int) for x in parsed):
            click_grid_cells(driver, parsed)
        else:
            inject_hidden_response(driver, solution)
    else:
        # Hidden input response
        inject_hidden_response(driver, solution)

    # Submit
    submit = driver.find_element(
        By.CSS_SELECTOR, "button[type='submit'], .submit-btn, #verify"
    )
    submit.click()

    return True

Fehlerbehebung

FAQ

Woher kennt CaptchaAI das Rasterlayout?

CaptchaAI empfängt die CAPTCHA-Herausforderung von den BLS-Servern und löst sie aus der Ferne. Sie geben den Sitekey und die PageURL an; Die API übernimmt die Rasteranalyse.

Was passiert, wenn sich das Raster ändert, nachdem ich es eingereicht habe?

Einige BLS-Formulare zeigen eine zweite Herausforderung, nachdem die erste bestanden wurde. Behandeln Sie dies, indem Sie nach der Übermittlung nach einem neuen CAPTCHA-Element suchen.

Kann ich eine BLS-Grid-Lösung wiederverwenden?

Nein. Jede Lösung ist an eine bestimmte Challenge-Sitzung gebunden. Immer frisch lösen.
